95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment

95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment

    • 95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment

    Produktdetails:

    Herkunftsort: China
    Markenname: IKP
    Zertifizierung: CE/UL/REACH/ROHS
    Modellnummer: Toroidaltransformator

    Zahlung und Versand AGB:

    Min Bestellmenge: 1000
    Preis: 3.00-20.00
    Verpackung Informationen: Karton
    Lieferzeit: 10-15 Tage
    Zahlungsbedingungen: L/c, t/t
    Supply Ability: 100,000/week
    Kontakt
    Ausführliche Produkt-Beschreibung

    Specifications:

    • Power range:100VA to 1000VA

    • Input / Output: Customized

    • Insulation Class: UL class B, F, H, N (optional)

    • Isolation: 4KV (Hi-pot)

    • Easy to change diameter and height of the core

    • Customized specifications are welcome

    Rated Power

    (VA)

    Outside Dimension

    D*H(mm)

    Weight

    (kg)

    Temp. Rise

    (℃)

    		Approval
    100 95*45 1.24 51 UL/CE/RoHS/CQC
    300 125*56 2.95 53 UL/CE/RoHS/CQC
    500 140*65 4.20 55 UL/CE/RoHS/CQC
    600 146*71 5.20 56 UL/CE/RoHS/CQC
    800 170*65 6.30 57 UL/CE/RoHS/CQC
    1000 170*75 7.20 58 UL/CE/RoHS/CQC



    ◆We can design and manufacture customized part with specific requirement



    95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement



    95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment95*45mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
