120*60mm Outside Dimension D*H Toroidal Transformer for Medical

120*60mm Outside Dimension D*H Toroidal Transformer for Medical

    • 120*60mm Outside Dimension D*H Toroidal Transformer for Medical
    • 120*60mm Outside Dimension D*H Toroidal Transformer for Medical
    • 120*60mm Outside Dimension D*H Toroidal Transformer for Medical
    • 120*60mm Outside Dimension D*H Toroidal Transformer for Medical
    • 120*60mm Outside Dimension D*H Toroidal Transformer for Medical
    • 120*60mm Outside Dimension D*H Toroidal Transformer for Medical
    • 120*60mm Outside Dimension D*H Toroidal Transformer for Medical

    Produktdetails:

    Herkunftsort: China
    Markenname: IKP
    Zertifizierung: CE/UL/REACH/ROHS
    Modellnummer: Toroidaltransformator

    Zahlung und Versand AGB:

    Min Bestellmenge: 1000
    Preis: 3.00-20.00
    Verpackung Informationen: Karton
    Lieferzeit: 10-15 Tage
    Zahlungsbedingungen: L/c, t/t
    Versorgungsmaterial-Fähigkeit: 100.000/Woche
    Kontakt
    Ausführliche Produkt-Beschreibung

    Specifications:

    • Power range:100VA to 10KVA

    • Input / Output: Customized

    • Insulation Class: UL class B, F, H, N (optional)

    • Isolation: 4KV (Hi-pot)

    • Easy to change diameter and height of the core

    • Customized specifications are welcome

    Rated Power

    (VA)

    Outside Dimension

    D*H(mm)

    Weight

    (kg)

    Temp. Rise

    (℃)

    		 Approval
    100 100*50 1.25 51 UL/CE/RoHS/CQC
    230 120*60 2.35 53 UL/CE/RoHS/CQC
    400 140*60 3.57 54 UL/CE/RoHS/CQC
    600 155*75 5.12 56 UL/CE/RoHS/CQC
    750 165*77 6.37 57 UL/CE/RoHS/CQC
    1000 175*88 8.50 58 UL/CE/RoHS/CQC
    1500 208*100 11.70 59 UL/CE/RoHS/CQC
    2000 208*125 14.70 60 UL/CE/RoHS/CQC
    2500 215*130 17.70 61 UL/CE/RoHS/CQC
    3000 225*140 20.12 62 UL/CE/RoHS/CQC
    5000 260*150 29.20 63 UL/CE/RoHS/CQC
    10000 320*155 51.00 65 UL/CE/RoHS/CQC


    ◆We can design and manufacture customized part with specific requirement



    120*60mm Outside Dimension D*H Toroidal Transformer for Medical

    120*60mm Outside Dimension D*H Toroidal Transformer for Medical

    120*60mm Outside Dimension D*H Toroidal Transformer for Medical120*60mm Outside Dimension D*H Toroidal Transformer for Medical120*60mm Outside Dimension D*H Toroidal Transformer for Medical
